MKP-L DC-Link塑殼系列
| 產品說明： |
|
★特點
□壽命長
□承受紋波電流能力強
□等效串聯電阻小、雜散電感低
□自愈能力強
★應用場合
□應用于直流濾波場合
★技術要求
引用標準 | GB/T17702，IEC61071 |
氣候類別 | 40/85/21 |
工作溫度范圍（外殼） | -40～85 |
電壓范圍 | 500～1100V.DC |
容量范圍 | 5～100μF |
容量允許偏差 | ±5%（J）/±10%（K） |
損耗角正切值 | ≤10×10-4 |
耐電壓 | 1.5Un（60S，20±5℃） |
絕緣電阻 | ≥10 000s （20±5℃ 100V.DC 60S） |
過電壓 | 1.1Un 30% of on-load-dur.·0 |
1.15Un 30min/day | |
1.2Un 5min/day | |
1.3Un 1min/day | |
最高使用海拔 | 2000m |
預期壽命 | 100 000h（Un，θhs=70℃） |
失效率 | 50FIT |
備注：如果海拔使用高度超過2000m，應該考慮海拔對對流冷卻和外絕緣的影響
★技術參數
500VDC | ||||||||||
Cn (μF) | Dimension(mm) | dv/dt (V/μs) | Irms@60℃@10KHz（A） | ESR@1KHz (mΩ) | Part number | |||||
L | B | H | P | P2 | d | |||||
16 | 42.5 | 22 | 30 | 37.5 | 1.2 | 20 | 10 | 7.9 | 1GLBH616D500--- | |
25 | 42.5 | 28 | 37 | 37.5 | 1.2 | 20 | 12 | 5.5 | 1GLBH625D500--- | |
25 | 42.5 | 28 | 37 | 37.5 | 10 | 1.2 | 20 | 14 | 5.3 | 1GLBH625D500--- |
35 | 42.5 | 30 | 45 | 37.5 | 1.2 | 20 | 12 | 4.0 | 1GLBH635D500--- | |
35 | 42.5 | 30 | 45 | 37.5 | 20 | 1.2 | 20 | 17 | 3.8 | 1GLBH635D500--- |
40 | 42.5 | 33 | 45 | 37.5 | 1.2 | 20 | 12 | 3.6 | 1GLBH640D500--- | |
40 | 42.5 | 33 | 45 | 37.5 | 20 | 1.2 | 20 | 19 | 3.5 | 1GLBH640D500--- |
50 | 57.5 | 30 | 45 | 52.5 | 1.2 | 13 | 12 | 5.2 | 1GLBH650D500--- | |
50 | 57.5 | 30 | 45 | 52.5 | 20 | 1.2 | 13 | 17 | 5.0 | 1GLBH650D500--- |
65 | 57.5 | 35 | 50 | 52.5 | 1.2 | 13 | 12 | 4.5 | 1GLBH665D500--- | |
65 | 57.5 | 35 | 50 | 52.5 | 20 | 1.2 | 13 | 20 | 4.3 | 1GLBH665D500--- |
90 | 57.5 | 42.5 | 50 | 52.5 | 20 | 1.2 | 13 | 25 | 3.7 | 1GLBH690D500--- |
100 | 57.5 | 35 | 50 | 52.5 | 20 | 1.2 | 10 | 20 | 3.0 | 1GLBH710D500--- |
800VDC/900VDC | ||||||||||
Cn (μF) | Dimension(mm) | dv/dt (V/μs) | Irms@60℃@10KHz（A） | ESR@1KHz (mΩ) | Part number | |||||
L | B | H | P | P2 | d | |||||
10 | 42.5 | 22 | 30 | 37.5 | 1.2 | 30 | 8 | 9.5 | 1GLBH610D800-- | |
15 | 42.5 | 28 | 37 | 37.5 | 1.2 | 30 | 11 | 6.5 | 1GLBH615D800-- | |
15 | 42.5 | 28 | 37 | 37.5 | 1.2 | 30 | 11 | 6.0 | 1GLBH615D800-- | |
20 | 42.5 | 30 | 45 | 37.5 | 1.2 | 30 | 12 | 5.0 | 1GLBH620D800-- | |
20 | 42.5 | 30 | 45 | 37.5 | 20 | 1.2 | 30 | 13 | 4.5 | 1GLBH620D800-- |
22 | 42.5 | 33 | 45 | 37.5 | 1.2 | 30 | 12 | 4.6 | 1GLBH622D800-- | |
22 | 42.5 | 33 | 45 | 37.5 | 20 | 1.2 | 30 | 15 | 4.1 | 1GLBH622D800-- |
30 | 57.5 | 30 | 45 | 52.5 | 1.2 | 20 | 12 | 6.4 | 1GLBH630D800-- | |
30 | 57.5 | 30 | 45 | 52.5 | 20 | 1.2 | 20 | 15 | 5.9 | 1GLBH630D800-- |
40 | 57.5 | 35 | 50 | 52.5 | 1.2 | 20 | 12 | 4.9 | 1GLBH640D800-- | |
40 | 57.5 | 35 | 50 | 52.5 | 20 | 1.2 | 20 | 19 | 4.4 | 1GLBH640D800-- |
55 | 57.5 | 42.5 | 56 | 52.5 | 20 | 1.2 | 20 | 24 | 3.0 | 1GLBH655D800-- |
1100VDC/1200VDC | ||||||||||
Cn (μF) | Dimension(mm) | dv/dt (V/μs) | Irms@60℃@10KHz（A） | ESR@1KHz (mΩ) | Part number | |||||
L | B | H | P | P2 | d | |||||
6 | 42.5 | 22 | 30 | 37.5 | 1.2 | 39 | 8 | 12 | 1GLBH560D1100-- | |
10 | 42.5 | 28 | 37 | 37.5 | 1.2 | 39 | 10 | 8.0 | 1GLBH610D1100-- | |
10 | 42.5 | 28 | 37 | 37.5 | 10 | 1.2 | 39 | 10 | 7.5 | 1GLBH610D1100-- |
14 | 42.5 | 30 | 45 | 37.5 | 1.2 | 39 | 13 | 5.8 | 1GLBH614D1100-- | |
14 | 42.5 | 30 | 45 | 37.5 | 20 | 1.2 | 39 | 13 | 5.3 | 1GLBH614D1100-- |
15 | 42.5 | 33 | 45 | 37.5 | 1.2 | 39 | 13 | 5.5 | 1GLBH615D1100-- | |
15 | 42.5 | 33 | 45 | 37.5 | 20 | 1.2 | 39 | 15 | 5.0 | 1GLBH615D1100-- |
22 | 57.5 | 30 | 45 | 52.5 | 1.2 | 26 | 13 | 7.2 | 1GLBH622D1100-- | |
22 | 57.5 | 30 | 45 | 52.5 | 20 | 1.2 | 26 | 16 | 6.7 | 1GLBH622D1100-- |
25 | 57.5 | 35 | 50 | 52.5 | 1.2 | 26 | 14 | 6.4 | 1GLBH625D1100-- | |
25 | 57.5 | 35 | 50 | 52.5 | 20 | 1.2 | 26 | 18 | 5.9 | 1GLBH625D1100-- |
40 | 57.5 | 42.5 | 56 | 52.5 | 20 | 1.2 | 26 | 25 | 3.5 | 1GLBH640D1100-- |
